Product Details
BC Racing ZX Series Coilovers for the 2004-2013 Mazda 3 (BK3P) bring the same three-axis adjustability as the race-spec ZR Series with valving tuned for drivers who split time between street and track. Every kit is extensively tested on the 3 BK3P chassis and refined until it balances ride quality with performance — the reason 3 coilovers from BC Racing are the best-selling adjustable kits in their segment worldwide.
ZX Series kits share the three-axis damper architecture of the race-spec ZR Series, tuned out of the box for drivers who want race-grade adjustability without the ride harshness on the commute home. The off-the-shelf setup from BC Racing is deliberately balanced — spring rates and valving chosen so the kit feels comfortable day-to-day without giving up performance when you push it. Drivers who want a different recipe can spec Swift Springs, custom spring rates, or fully custom valving at checkout; BC will tune the dampers to match, which is a depth of customization most brands only offer on their top-tier kits.
BC Racing's reputation in the aftermarket suspension world is built on four things: competitive pricing that beats the rest of the fully-adjustable market, customization depth that rivals the top-tier race brands, long-term reliability earned over 20 years of production, and a rebuildable design that keeps the same set of dampers serving you through multiple builds. These 3 coilovers arrive tuned for the BK3P chassis and ready to bolt in — no break-in period, no guessing at setup. Every kit ships with a 2-year manufacturer warranty, lifetime access to BC service parts (pistons, seals, shafts — no unit replacement required when it's time for a rebuild), and in-house tech support from both BC Racing and the Springrates team.
Features
- 30-level rebound adjustment
- 15-level low-speed compression adjustment
- 12-level high-speed compression adjustment
- Inverted mono-tube damper with linear twin-piston design
- Ride height adjustable independent of spring preload
- Upper mount hardware varies by chassis — camber plates, pillowball, or reused OEM mounts. See the Specifications table for what's included on your kit.
- Swift Spring and custom spring rate upgrades available at checkout
- Custom damper valving paired with custom spring rates on request
- Fully rebuildable — replacement parts available from BC for the life of the shock
- 2-year manufacturer warranty against defects
Specifications
| Part Number | N-03-ZX |
| Part Name | ZX Series Coilovers |
| Vehicle | 2004-2013 Mazda 3 FWD (BK3P) |
| Drivetrain | FWD |
| Chassis Code | BK3P |
| Damping Adjustment | 3-Way (30 levels rebound 15 LSC 12 HSC) |
| Ride-Height Adjustable | Yes |
| Spring Rate - Front | 6 kg/mm |
| Spring Rate - Rear | 4 kg/mm |
| Spring Size - Front | 62-170-6K |
| Spring Size - Rear | 62-170-4K |
| Swift Springs - Front | 62-178-X |
| Swift Springs - Rear | 62-178-X |
| Camber Plates - Front | Included |
| Camber Plates - Rear | Not Applicable |
| Suspension Design - Front | True Coilover |
| Suspension Design - Rear | True Coilover |
| Notes | The ZX Series is not available in Extreme-Low configuration. |
Vehicle Fitment
- 2004 Mazda 3 FWD (BK3P)
- 2005 Mazda 3 FWD (BK3P)
- 2006 Mazda 3 FWD (BK3P)
- 2007 Mazda 3 FWD (BK3P)
- 2008 Mazda 3 FWD (BK3P)
- 2009 Mazda 3 FWD (BK3P)
- 2010 Mazda 3 FWD (BK3P)
- 2011 Mazda 3 FWD (BK3P)
- 2012 Mazda 3 FWD (BK3P)
- 2013 Mazda 3 FWD (BK3P)
