Product Details
BC Racing ZR Series Coilovers for the 1992-1995 Mitsubishi Lancer Evo 1/2/3 (CE9A/CD9A) deliver the deepest damping adjustability in BC Racing's lineup, with Swift Springs included standard and three axes of independent tuning for competitive track programs. Every kit is extensively tested on the Lancer Evo 1/2/3 chassis and refined until it balances ride quality with performance — the reason Lancer Evo 1/2/3 coilovers from BC Racing are the best-selling adjustable kits in their segment worldwide.
ZR Series kits use an inverted mono-tube damper with a linear twin-piston design, feeding three independent adjustment circuits. Swift Springs come standard — not as an upgrade — and the kit is race-tuned out of the box. BC Racing takes pride in choosing spring rates and damper valving that balance comfort and performance — you never end up with the oversprung, harsh-riding kit some brands ship as their only option. Drivers who want to deviate from the factory setup can order Swift Springs, custom spring rates, and custom valving at checkout; BC will re-valve the dampers to match whatever you specify, a level of customization most brands reserve for their top-tier race kits.
BC Racing has been manufacturing adjustable coilovers since 2004 and is one of the most popular coilover brands in the automotive tuning industry for a reason: competitive pricing, deep customization, proven reliability, and a fully rebuildable damper design that lasts years instead of seasons. These Lancer Evo 1/2/3 coilovers arrive tuned for the Lancer Evo 1/2/3 chassis and ready to bolt in — no break-in period, no guessing at setup. Every kit ships with a 2-year manufacturer warranty, lifetime access to BC service parts (pistons, seals, shafts — no unit replacement required when it's time for a rebuild), and in-house tech support from both BC Racing and the Springrates team.
Features
- 30-level rebound adjustment
- 15-level low-speed compression adjustment
- 12-level high-speed compression adjustment
- Inverted mono-tube damper with twin-piston design
- Swift Springs come standard
- Ride height adjustable independent of spring preload
- Upper mount hardware varies by chassis — camber plates, pillowball, or reused OEM mounts. See the Specifications table for what's included on your kit.
- Custom spring rates and custom valving available at checkout
- Fully rebuildable — replacement parts available from BC for the life of the shock
- 2-year manufacturer warranty against defects
Specifications
| Part Number | B-17-ZR |
| Part Name | ZR Series Coilovers |
| Vehicle | 1992-1995 Mitsubishi Lancer Evo 1/2/3 AWD (CE9A/CD9A) |
| Drivetrain | AWD |
| Chassis Code | CE9A/CD9A |
| Damping Adjustment | 3-Way (30 levels rebound / 15 LSC / 12 HSC) |
| Ride-Height Adjustable | Yes |
| Spring Rate - Front | 6 kg/mm |
| Spring Rate - Rear | 4.5 kg/mm |
| Spring Size - Front | 62-200-6K |
| Spring Size - Rear | 62-220-4.5K |
| Swift Springs - Front | 62-203-X |
| Swift Springs - Rear | 62-228-X |
| Camber Plates - Front | Included |
| Camber Plates - Rear | Not Applicable |
| Suspension Design - Front | True Coilover |
| Suspension Design - Rear | True Coilover |
| Notes |
|
Vehicle Fitment
- 1992 Mitsubishi Lancer Evo 1/2/3 AWD (CE9A/CD9A)
- 1993 Mitsubishi Lancer Evo 1/2/3 AWD (CE9A/CD9A)
- 1994 Mitsubishi Lancer Evo 1/2/3 AWD (CE9A/CD9A)
- 1995 Mitsubishi Lancer Evo 1/2/3 AWD (CE9A/CD9A)
